2U 32 Amp AC Rack Mount PDU With 8 x Neutrik powerCon Sockets

Part No
£427.03 £355.86
In stock
2U 32 Amp AC Rack Mount PDU With 8 x Neutrik powerCon Sockets, Overload Protection & Power Monitoring

2U high Horizontal Mounting unit designed to provide versatile hook-up for the distribution of AC power within Multimedia Theatre & Touring rack applications.

Circuit A:
Main Input - C-FORM 240V 32A IP44 Panel Mount Appliance Inlet
Protection - Illuminated Circuit Breaker overload protection between dual 16A sockets
Output - C-FORM 240V 16A IP44 Panel Mount Appliance Outlet

Circuit B:
Output - 8 Neutrik powerCon sockets with a Maximum Combined Load 16A.
Protection - Illuminated Circuit Breaker 16A overload protection
LCD Monitor - LCD Power Monitor giving Voltage, Current, Power, Energy Levels & Overload Alarm.
Earth Link - M4 Screw Terminal for Rack Grounding

Nominal Voltage: 110V-240V
Usable Voltages: 110V-240V full range
Frequency: 50/60HZ full range
Max. A/C Output: Current 16A
Case Size: 88mm x 140mm x 430mm (O.A. 483mm)
Weight: 2.5kg

All components used in this conform to current RoHS, CE & UL certification - E&OE (EMI:EN55022 (CISPR22) Class B; EN61000-3-2,3 EMS:EN61000-4-2,3,4,5,6,8,11; Light industry level, criteria A)
Technical Information
Number of Sockets 8 Sockets
Plug Type powerCON
Size (U) 2U
Weight 2.5kg
Customer Questions
Is there anyway this could be customised, as i do not require a 16a ceeform output but require a total load of 32a across the powercons? Ideally I would like 4 powercon per 16a circuit.
Thank you for your enquiry, We have a 16amp version here - https://www.pennelcomonline.com/en/Penn-Elcom-16A-Rack-Mount-PDU-powerCon-Sockets-PDU16-PC/m-9947.aspx We do manufacturer these products. If you would like a custom version please contact...
Similar to the last question. Can this be customised. We don’t need the 16A cee form outlet but we do need all 32A to be available across the powercon outlets.
Thank you for your enquiry, Yes we can offer a customisation service. Please email your request and we will provide a quotation. Regards Penn Elcom
